Arducam GMSL2 8MP Camera Extension Kit for NVIDIA Jetson Orin Nano/Orin NX

Arducam GMSL2 8MP Camera Extension Kit for NVIDIA Jetson Orin Nano/Orin NX Overview The Arducam RapidRange G2 GMSL2 Camera Kit is an advanced solution for long-distance imaging and video transmission, especially suitable for robotics and other fields. Originally developed for the automotive industry, GMSL (Gigabit Multimedia Serial Link) technology is now also expanding to applications in the fields of robotics, precision agriculture, smart cities and advanced healthcare systems. The technology offers a reliable and extremely fast video connection, enabling high-quality data flow without compromise. The Arducam RapidRange G2 Kit maximizes the capabilities of GMSL2, providing an ideal solution for long-distance imaging, helping to increase efficiency and innovation in a variety of industrial fields. The 8MP GMSL2 Camera Expansion Kit for NVIDIA Jetson Orin Nano / Orin NX enables imaging up to 15 meters away without loss of image quality. The system is based on ADI’s advanced SerDes technology, which provides high bandwidth and extremely low latency. The system is equipped with an 8-megapixel SONY IMX219 sensor, which provides high image quality, simple installation and signal transmission with only one cable. In addition, there is also support for GMSL1 for convenient adaptation and easy upgrade of existing systems. Main Applications Robotics Autonomous Mobile Robots (AMR) Precision Agriculture Security and Control Systems Smart Cities and IoT Devices Main Features [Long-Distance Shooting] High-quality and reliable shooting at distances of up to 15 meters, while maintaining image sharpness and without compromising video quality, even at extended ranges. [GMSL2 Technology] Utilizes ADI’s advanced SerDes technology, which provides extremely high bandwidth, low latency, and high-speed data transfer for smooth and stable video transmission. [High-Quality Transmission] Equipped with an 8-megapixel SONY IMX219 sensor, ensuring sharp images, vivid colors, and precise details even in applications that require high quality. [Simple and Cost-Effective Installation] Transmitting signals in a single cable simplifies the installation process, reduces weight and power consumption, and eliminates the need for additional cables – an efficient and cost-effective solution. [Backward Compatibility] Supports GMSL1 serializers (as specified in the technical specifications), for a smooth and simple upgrade to GMSL2, without the need for complex changes to an existing system. [Various Uses] Although originally designed for the automotive sector, the system is also suitable for robotics, security, industrial automation, precision agriculture, smart cities and more – and enables reliable video connection even in challenging environments. Specifications Image Sensor Sensor Model: SONY IMX219 Still Resolution: 8 MP Color Filter Type: Color Shutter Type: Rolling Shutter Optical Size: 1/4 inch Output Format: RAW10 Pixel Size: 1.12 × 1.12 microns Sensor Active Area: 3280 × 2464 pixels Video Modes: 3280 × 2464 at 21fps 3280 × 1848 at 28fps 1920 × 1080 at 30fps 1640 × 1232 at 30fps 1280 × 720 at 60fps Lens Focus Type: Fixed Focus Angle of View (FOV): 80° (D) × 62.2° (H) × 48.8° (V) Lens Mount: Lens Built-in (Stock Lens) Aperture (F.NO): F2.0 Effective Focal Length (E.F.L): 3.04 mm Default Focus Range: 20 cm to Infinity Infrared Light Sensitivity: Built-in IR-cut Filter Electrical and Mechanical Specifications Operating Voltage: Adapter Card: 5V / 1A Camera: 3.3V / 500mA Working Temperature: -20°C to 85°C Power Consumption: 6.6W Camera Board Dimensions: 24 × 25 mm Functionality and Compatibility Transmission Cable: Supports Power-over-Coax (PoC) GMSL Cable Length: Up to 15 meters What’s Included in the Kit? 1 × Arducam GMSL2 Receiver (Rx) Board 1 × Arducam GMSL2 Camera Transmitter (Tx) Board 1 × Coaxial Cable Fakra Z 1m (Female to Female) 1 × Arducam IMX219 Camera Module 1 × 40mm 22-22pin FPC Cable 1 × 300mm 22-22pin FFC Cable 1 × Screw Kit
