Arducam GMSL2 12MP Camera Extension Kit for Raspberry Pi Arducam GMSL2 12MP Camera Extension Kit for Raspberry Pi The Arducam RapidRange G2 GMSL2 is an advanced long-distance video and imaging solution for robotics and other industrial applications. Originally developed for the automotive industry, GMSL (Gigabit Multimedia Serial Link) technology is now being extended to areas such as robotics, precision agriculture, smart cities and digital health, providing fast, reliable and high-bandwidth video connectivity. The Arducam RapidRange G2 kit leverages the capabilities of GMSL2 to offer an ideal long-distance video and imaging solution, improving efficiency and innovation in a variety of industries. The 12MP GMSL2 camera extension kit for Raspberry Pi allows for imaging from up to 15 meters away without loss of quality. The kit is based on ADI’s SerDes technology and provides high bandwidth with extremely low latency. The camera features a 12-megapixel SONY IMX477 sensor for ultra-high image quality, and allows for simple installation with signal transmission over just one cable. Additionally, there is GMSL1 backward support for existing installations. Main Applications Robotics Autonomous Mobile Robots (AMR) Precision Agriculture Surveillance and Security Systems Industrial Automation IoT and Smart City Solutions Main Features [Long-Distance Shooting] Transmit high-quality and stable video up to a range of 15 meters, without compromising image quality or performance. [GMSL2 Technology] Based on ADI’s advanced SerDes technology, which provides ultra-fast data transfer with minimal latency, for a smooth and professional video experience. [High-Quality Transmission] The camera is equipped with a SONY IMX477 sensor with a resolution of 12 megapixels, ensuring high sharpness, impressive detail and accurate color reproduction. [Simple and Cost-Effective Installation] The signal is transmitted via only one cable, which simplifies installation and reduces weight, power consumption and operating costs. [Backward Compatibility] Support for GMSL1 serializers according to the specification, for easy upgrade and integration into existing systems. [Various Uses] Suitable not only for the automotive sector – also ideal for robotics, security systems, precision agriculture, industrial automation, smart cities and more. Technical specifications Image sensor Sensor model: SONY IMX477P Still resolution: 12.3 megapixels Color filter type: Color Shutter type: Rolling Shutter Optical size: 1/2.3 inch Output format: RAW12 Pixel size: 1.55×1.55 microns Active area: 4056 × 3040 pixels Video modes: 2028 × 1080p at 50fps 2028 × 1520p at 40fps 1332 × 990p at 120fps Lens Focus: Manual focus Angle of view (FOV): 88° (D) × 75° (H) × 60° (V) Lens mount: M12 Aperture (F.NO): F2.8 Effective focal length (E.F.L): 3.9 mm Focus range: 1.7 meters – infinity Image distortion: less than 0.3% Electrical and mechanical specifications Operating voltage: Adapter card: 5V / 1A Camera: 3.3V / 500mA Operating temperature: from –20°C to 85°C Power consumption: 6.6W Camera board size: 24×25 mm Functionality and compatibility Transmission cable: Supports Power-over-Coax (PoC) GMSL cable length: up to 5 meters What’s in the kit? 1 × Arducam GMSL2 Receiver (Rx) End Board 1 × Arducam GMSL2 Camera Transmitter (Tx) Board 1 × 1m Fakra Z Coaxial Cable (Female to Female) 1 × Arducam IMX477 Camera Module 1 × 40mm 22-22pin FPC Cable 1 × 80mm 22-22pin FPC Cable 1 × 73mm 15-22pin FFC Cable 1 × Screw Kit
