Electroweld Portable Spot Welder Gun with Foot Pedal Operated Stand 6KVA SP-6 – Spot Welder Gun Electroweld Portable Spot Welder Gun with Foot Pedal Operated Stand 6KVA (SP-6HG-PS) Product Functionality: Portable Hand Operated Spot Welders are designed for extraordinary versatility and are designed for various uses where the job cannot be taken to the welding machines like in metal fabrication shops, manufacturing of automobile bodies and sub-assemblies. This unit comes with a sturdy Foot Pedal Operated Mountable Stand, which enables you to operate the Electroweld Portable Spot Welder just like a stationary unit. Depressing the foot pedal, clamps the portable welder arms and performs the weld as per the settings programmed on the portable welder’s controller. Releasing the foot pedal, when the weld is complete unclamps the portable welder arms and releases the welded job. This allows the operator two free hands for handling the job to be welded. The portable welder slips onto the stand and is riveted in position using 4-bolts and can be easily unmounted from the stand when needing to use the welder as a Portable Handheld Unit. Applications Include: Spot welding, electro-brazing, cross wire welding,etc.The machines are also capable of welding stainless steel, brass, phosphor, bronze, alloy steels, etc. Specific details can be had on request. Construction: The portable spot gun is ruggedly fabricated with streamlined appearance, suitably stiffened at points of stress. Designed with an air cooled integrated transformer structured for low impedance with immense short circuit current, accurate cooling and padding along with winding impregnation to strengthen reliability and service life. The transformer is mounted directly on to the body and the bearings for the arm are provided in the same. Adjustment of Electrode Force: Via Adjustment of electrode stroke via adjustable mechanical joint provided in the machine. Adjustment of Electrode Stroke: Via vertical adjustment of electrode Current Control: Current Control by change of Transformer tap links Weld Initiation: Weld Initiation by means of Hand Operated Limit Switch. Simple Lever Function – To perform welding applications, simply apply pressure and press down on the lever. Gun is designed for maximum flexibility to produce high pressure on electrodes with minimum user force Electronic Control: Solid State Precision Electronic Timer provided for squeeze and weld Electroweld Portable Hand Operated Spot welder Gun with Integrated Transformer 6KVA @ 50% Duty Cycle (SP-6HG) Electroweld Portable Spot Welder Gun with Foot Pedal Operated Stand 6KVA is available through HeatSource.
